Ironworks Speed & Kustom ECU Mounting Bracket


Ironworks Speed & Kustom has been selling ECU brackets to mount those hard to mount ECU's for about a year now. I wanted to post up some further info on how the brackets are designed to be used and info on how to purchase them.

LS1 ECU bracket - These are made from .090 steel and are laser cut and press broke parts. We powder coated this bracket Orange to make it stand out. All brackets come in bare steel so you can weld on them or weld them in to your project. We sell these brackets for $45.00.

http://i616.photobucket.com/albums/t...0Parts/010.jpg
http://i616.photobucket.com/albums/t...0Parts/008.jpg

LS2-LS9 ECU bracket - These brackets are made from .090 and .125 steel. We have again powder coated these orange for display purposes. They have a 2.625" leg on the ends that can be trimmed or cut to fit your desired location under the dash or engine compartment location. These sell for $40.00

http://i616.photobucket.com/albums/t...Parts/0062.jpg
http://i616.photobucket.com/albums/t...Parts/0042.jpg

We also sell brackets to mount the MAST ECU, FAST XFI, BIG STUFF. These all sell for $40.00 each also.

http://i616.photobucket.com/albums/t...ary2011007.jpg
http://i616.photobucket.com/albums/t...ber2010012.jpg

LS1 ECU install pictures


Here is how we mounted the ECU on Frank's 48 under the dash with our ECU bracket. We just stitch welded the ECU to the back side of the firewall.

http://i616.photobucket.com/albums/t...ber2010028.jpg



Here are a few pics of how we mounted the ECU bracket in the Donkey Kong Project.

http://i616.photobucket.com/albums/t...ary2011006.jpg
http://i616.photobucket.com/albums/t...ust2011060.jpg
http://i616.photobucket.com/albums/t...ary2011008.jpg

We now have these brackets available for purchase on our website.

those are nice Rodger. Professional looking, saves fab time, and not expensive. :thumbsup:

That was the whole entire point of them. Thanks


I'm working on a few other slick parts like this.

I would love an LS1 bracket.....do you ship to canada using USPS? If so I'll take one.

Yes we do. Just order the bracket online and we will ship it right out.

I'll be ordering a bracket in the near future. Oh, love the new website too. :woot:

Thanks I did most of the site myself.

Noticed on the site that you have a C10 chassis coming soon too. I'll be watching for that one Roger. :thumbsup: :thumbsup:
