autocad Drawing of '62 Nova

What do you guys think?
http://i26.photobucket.com/albums/c1...62novadraw.jpg

XcYZ	11-15-2006 07:27 AM

Better than I could do, but I think your wheels are a bit small.

XTRMEASURES

11-15-2006 06:46 PM

yea make the rims bigger

WhitecatD

11-17-2006 04:04 PM

Is this better?
http://i26.photobucket.com/albums/c1...62novadrw2.jpg

PASD U

11-19-2006 07:01 PM

I would say you not only need to make the wheels even larger/proportionate, but enlarge both wheel well openings and bring the front wheel well midway between the leading edge door jam and the front grill.

This might make it look closer in scale.

p_call

02-10-2007 08:37 PM

If you want to "cheat", you can find a side photo of a nova and copy/paste it into autocad. Then draw the wheels, ect over the photo. AutoCAD is a little temperamental when you do this, but I have done it several times at work to get a pretty close wireframe quickly.
