Vision
The tasteful integration of modern styling and technology into the classic 1970 Pontiac Formula Firebird body. Built as a high-performance daily driver, this Firebird will include many luxuries and appointments found in late model sports cars such as a tuned suspension, fuel injected adjustable twin-turbos, climate control, power windows and state-of-the art stereo and multimedia electronics. The body modifications provide a contemporary yet bold look and will increase performance by managing and directing airflow.

Engine - 475 Cu. In. Custom Twin Turbo Pontiac
Block - IAII cast iron 4.250" bore.
Mains - billet 3.00" splayed mains,
Crank - 4.00" stroke crank - Scat 4340 forged steel
Rods - 6.800" Eagle - Forged H-beam rods with ARP2000 rod bolts
Pistons - (( Steve Morris Engines Custom design turbo pistons with hard anodizing and H13 tool steel pins))
Rings - ((Total Seal piston rings AP steel top and napier seconds))
Bearings - Federal Mogul bearings H-series
Heads - Kauffman - CNC ported 380cc high port aluminum heads assembled complete
Rocker arms - Jesel shaft mount rockers modified by Steve Morris Engines
Head Gaskets - Cometic MLS .040" head gaskets
Cam - Comp Cams custom ground hydraulic roller turbo cam with All Speed Customs specs furnished Comp Cams
Lifters - Johnson hyd lifters
Push rods - Engine Pro .083" wall chromoly pushrods
Pan - Canton- 7 qt. deep road/drag race pan with pick-up
Oil Pump - Melling HV
Comp Cams billet adjustable timing chain
Canton racing high capacity oil pan and pick up
Custom Visner Engines intake with dual fuel rails
Custom Visner Engines dual throttle bodies
Billet Specialties accessory drive
Aluminum radiator
SPAL dual 11� fan
Stainless bolts and hardware

Turbo system � Custom All Speed Performance Twin
2 ea. Bullseye Power 62 mm extended tip turbos with polished race covers
2ea. Tial 44 MM v-band wastegates
2 ea. Tial 50 MM blowoff valves
Custom air to air intercooler with aluminum charge tubing
Custom air hat with retro-Pontiac six pack design

Fuel System
Rick�s Stainless tank custom spec
Aeromotive Eliminator fuel pump with dual filters
Aeromotive fuel pump controller
Aeromotive stainless lines with aluminum reusable fittings

Exhaust
Custom stainless steel headers and 3.5� stainless steel exhaust with x-piping
Custom rear-exit exhaust manifold

Drive Train
Rockland Standard Gear 6 speed manual transmission
RAM dual disc clutch
Moser 12 bolt rearend
Truetrac 33 spline axles
Moser Pro-Street gears

Suspension and Brakes
DSE tubular upper and lower control arms with 2 �� drop
DSE 600 performance steering gear
DSE tubular tie rod adjusters
Delrin bushings
QA1 adjustable coilovers
DSE rear Quadra Link suspension with adjustable coilovers and 3� drop
Wilwood 6 piston calipers with 14� drilled and slotted front rotors
Wilwood 4 piston calipers with 14�drilled and slotted rear rotors
Wilwood aluminum tandem master cylinder
Wilwood proportioning valve and stainless brake lines
Hydroboost power brake system

Body Modifications
Custom front chin spoiler
Custom lower rocker side skirts
Custom exaggerated twin snorkel hood
Custom enlarged front valance openings
Custom front fender functioning vents
Custom reverse mohawk recessed roof to create twin silhouette cockpit
Custom reverse mohawk recessed deck lid with integrated spoiler
Custom rear valance with diffusers and center exit exhaust
Flared rear fenders
DSE mini-tubs
DSE subframe connectors
Smoothed and painted firewall
Custom wheel wells with turbo charger tubing receiver
Custom hood hinges
Smoothed and painted subframe
Custom billet door catch posts
Custom side mirrors
Custom roll cage

Paint and Coatings
PPG gloss black
Powder coated trim gloss black
Black ceramic coating on headers and turbos
Powder coat aluminum turbo piping gloss black
Painted block and heads gloss black
Painted gloss black valve covers with brushed �Pontiac� logo
Anodized fuel rails
Polished throttle bodies
Powder coated six-pack air hat

Interior
Custom design full leather interior with dual stitching
Front leather Corbeau bucket seats
Five point safety harness
Rear bench with molded buckets
Custom center console
Custom headliner
Original-reconditioned Trans Am gauges
New aluminum Trans Am dash plate
Power windows with billet switches
Custom billet door handles
Custom Budnik split-grip sport wheel anodized black with stainless hardware
Tinted windows
Vintage Air Sure Fit climate control system
Ididit tilt steering column
Ididit keyless ignition

Wheels and Tires
Aluminum performance 3-piece wheels 20� x 12.5� rear and 19� x 10� front
High performance front and rear tires

Electronics
Fast XFI engine management with touch screen dash/data logger
Painless wiring system
DSE battery relocation system with aluminum trunk mounts
Complete custom stereo with Digital Designs speakers, amplifiers, DVD and touch control screen
Integrated K-40 radar/laser detection system
Custom mobile office in trunk

Sponsors
Sun Title
All Speed Performance
Corbeau Seats
K&N Filters
Optima Batteries
Digital Designs
Wilwood Brakes
Detroit Speed and Engineering
Forgiato Wheels
FAST
QA1
Pirelli
Ididit

Build Participants
All Speed Performance
Steve Morris Engines
Cars by Kris
Excessive Audio
Burton Heights Body
Visner Engine Development
