Quote:
Originally Posted by Brianstanford View Post
Thanks! Why green instead of dexcool?
I can be wrong - it's my understanding is that dexcool works best with a factory sealed cooling system. So I used green type that works with all engine.

Believe it or not, I got my oil/coolant from the neighborhood Home Depot. They have the best prices compared to Walmart/Autopart store.
__________________
Tu Ho
67 Firebird (aka "Money Pit")-5.3/4l60e, restomod.
https://lateral-g.net/forums/showthread.php4?t=43170
Reply With Quote
  #112
Old 01-23-2019, 04:22 PM
Brianstanford Brianstanford is offline
Senior Member

Join Date: Jan 2017
Location: Houston, TX
Posts: 126
Thanks: 36
Thanked 16 Times in 10 Posts
Default

Well I got everything ready for a first start and had a couple of problems. Main on was oil pressure. Tried to prime motor with plugs out, no fuel or ignition relays. That didn't work. Tried to prime motor with pressurized oil tank, still no pressure. So I start to trouble shoot electrical. On the phone with psi and Dakota Digital. Both companies very helpful. Bim module wasn't reading the obd2 port. DD got me to verify that my bim was working properly by hooking it up to another vehicle and it worked as it should. So on the phone with psi we found that my oil pressure sensor wires were mixed up (black & brown swapped- fixed them) and a ground wire wasn't hooked up to the back of the head- I missed that one somehow. Go to crank engine over again and still nothing. Starting to think I may have punched the oil pickup tube o ring or something in the motor like bearings are shot. I'm stressing out. Motor is a 70-80k mile pull out. Sat in garage for 3 years. Installed holley 302-2 pan
__________________
Instagram @brianstanford
Reply With Quote
  #113
Old 01-23-2019, 04:23 PM
Brianstanford Brianstanford is offline
Senior Member

Join Date: Jan 2017
Location: Houston, TX
Posts: 126
Thanks: 36
Thanked 16 Times in 10 Posts
Default

I did start the motor for a couple 5-10 second runs to see if more rpm would build pressure. No luck with that either
__________________
Instagram @brianstanford
Reply With Quote
  #114
Old 01-23-2019, 06:49 PM
Spiffav8's Avatar
Spiffav8 Spiffav8 is online now
Lateral-g Moderator

Join Date: Apr 2007
Location: Las Vegas, NV
Posts: 4,379
Thanks: 86
Thanked 86 Times in 55 Posts
Default

Keep at it man!

__________________
Curtis
Pilots: We're not better than you, just way cooler.

NO ONE IS COMING. IT'S UP TO US.

http://www.navysealfoundation.org/
Reply With Quote
  #115
Old 01-23-2019, 07:42 PM
Gmachine1911's Avatar
Gmachine1911 Gmachine1911 is offline
Senior Member

Join Date: Oct 2017
Location: Southern IN
Posts: 341
Thanks: 16
Thanked 213 Times in 181 Posts
Default

Quote:
Originally Posted by Brianstanford View Post
Well I got everything ready for a first start and had a couple of problems. Main on was oil pressure. Tried to prime motor with plugs out, no fuel or ignition relays. That didn't work. Tried to prime motor with pressurized oil tank, still no pressure. So I start to trouble shoot electrical. On the phone with psi and Dakota Digital. Both companies very helpful. Bim module wasn't reading the obd2 port. DD got me to verify that my bim was working properly by hooking it up to another vehicle and it worked as it should. So on the phone with psi we found that my oil pressure sensor wires were mixed up (black & brown swapped- fixed them) and a ground wire wasn't hooked up to the back of the head- I missed that one somehow. Go to crank engine over again and still nothing. Starting to think I may have punched the oil pickup tube o ring or something in the motor like bearings are shot. I'm stressing out. Motor is a 70-80k mile pull out. Sat in garage for 3 years. Installed holley 302-2 pan

Might make sure you don't have a gauge issue. Would be worth hooking up a temporary mechanical gauge just to make sure you're not chasing your tail.
__________________
Shane
#theanchorholds

Link to my 68 Camaro build thread:
https://lateral-g.net/forums/showthread.php?t=56387

Link to my 67 Nova build thread:
https://lateral-g.net/forums/showthread.php?t=57769
Reply With Quote
  #116
Old 01-23-2019, 09:13 PM
Brianstanford Brianstanford is offline
Senior Member

Join Date: Jan 2017
Location: Houston, TX
Posts: 126
Thanks: 36
Thanked 16 Times in 10 Posts
Default

Quote:
Originally Posted by Gmachine1911 View Post
Might make sure you don't have a gauge issue. Would be worth hooking up a temporary mechanical gauge just to make sure you're not chasing your tail.
That's my next step! Like you said I'm not chasing something that's not
__________________
Instagram @brianstanford
Reply With Quote
  #117
Old 01-24-2019, 10:23 AM
rickpaw rickpaw is offline
Lateral-g Supporting Member

Join Date: Jan 2010
Location: Houston, Tx
Posts: 873
Thanks: 8
Thanked 14 Times in 13 Posts
Default

Quote:
Originally Posted by Brianstanford View Post
Well I got everything ready for a first start and had a couple of problems. Main on was oil pressure. Tried to prime motor with plugs out, no fuel or ignition relays. That didn't work. Tried to prime motor with pressurized oil tank, still no pressure
Quote:
Originally Posted by Gmachine1911 View Post
Might make sure you don't have a gauge issue. Would be worth hooking up a temporary mechanical gauge just to make sure you're not chasing your tail.
If you're priming it with a pressurized oil tank, and it's not showing pressure on the gauge, then I'd try a mechanical gauge to confirm, as Gmachine1911 suggested. Another thing to check is pull the valve covers while priming the motor with pressurized oil tank - oil should seep up thru the push rods.
__________________
Tu Ho
67 Firebird (aka "Money Pit")-5.3/4l60e, restomod.
https://lateral-g.net/forums/showthread.php4?t=43170
Reply With Quote
  #118
Old 01-24-2019, 12:32 PM
Brianstanford Brianstanford is offline
Senior Member

Join Date: Jan 2017
Location: Houston, TX
Posts: 126
Thanks: 36
Thanked 16 Times in 10 Posts
Default

Best $20 I've spent in a while

Cranking with a mechanical gauge, got pressure!!!!
Attached Images
File Type: jpg IMG_2588.jpg (87.8 KB, 0 views)
__________________
Instagram @brianstanford
Reply With Quote
  #119
Old 01-24-2019, 01:40 PM
Spiffav8's Avatar
Spiffav8 Spiffav8 is online now
Lateral-g Moderator

Join Date: Apr 2007
Location: Las Vegas, NV
Posts: 4,379
Thanks: 86
Thanked 86 Times in 55 Posts
Default

That's a gotta be a huge relief!
__________________
Curtis
Pilots: We're not better than you, just way cooler.

NO ONE IS COMING. IT'S UP TO US.

http://www.navysealfoundation.org/
Reply With Quote
The Following User Says Thank You to Spiffav8 For This Useful Post:
Brianstanford (01-24-2019)
  #120
Old 01-24-2019, 07:29 PM
Brianstanford Brianstanford is offline
Senior Member

Join Date: Jan 2017
Location: Houston, TX
Posts: 126
Thanks: 36
Thanked 16 Times in 10 Posts
Default

Quote:
Originally Posted by spiffav8 View Post
that's a gotta be a huge relief!
huge!
__________________
Instagram @brianstanford
Reply With Quote
