1969 Torino

[Track Junky]

Originally Posted by FETorino

Don't be shy Tracky. Or are you a agent for BMF sent to derail the Torino

Thats absurd. I have absolutely no idea what you're talking about

[FETorino]

Ron

Since the exercise is maximizing tire grip and we have been speaking of that exercise with a 200tw DOT tire.

If I tune the suspension to obtain the best balance possible with the DOT 200tw tires but then switch to a sticky compound tire such as a Hoosier R compound in the same proportional stagger does that warrant more spring, ARB and associated shock dampening?

Since the increased grip of the tires would allow for higher cornering speeds the forces working on the suspension should increase. I would think this means at a minimum more bar would be needed.

I would think you could use a similar spring package to control the pitch of the cars weight which is static but add more bar to deal with the added force from the increased cornering load.

Since I only really care a bout the 200tw tires for the RTTC or Goodguys type events a Hoosier R compound may actually be what I really tune for.

I'd like to understand the logic behind a slick vs street tire tune better. I'm sure others won't mind reading that little diddy either.



Sorry Gae

[Track Junky]

Originally Posted by FETorino

Sorry Gae

Your killin' me dude

Dont mind me...Carry on......Please

[Sieg]

The way this thread is going hopefully Ron's suspension spreadsheets have factoring to compensate for driver reaction times.

[Ron Sutton]

Hi Rob,

---------------------------------------------------------------------
Ron

Since the exercise is maximizing tire grip and we have been speaking of that exercise with a 200tw DOT tire.

If I tune the suspension to obtain the best balance possible with the DOT 200tw tires but then switch to a sticky compound tire such as a Hoosier R compound in the same proportional stagger does that warrant more spring, ARB and associated shock dampening?
Yes. Of course someone can simply switch tires & run the car to its limits. But if the car if going to be optimized with 200TW tires ... and also with Hoosier R6 race slicks ... the optimum set-up will be different.

Since the increased grip of the tires would allow for higher cornering speeds the forces working on the suspension should increase. I would think this means at a minimum more bar would be needed.
You will want to make changes in 4 areas. All requiring a small degree of work, but nothing complex. I'll outline it below.

I would think you could use a similar spring package to control the pitch of the cars weight which is static but add more bar to deal with the added force from the increased cornering load.
Sway bars are not enough. Because as you increase the traction of the tires, the car will experience a higher degree of weight transfer under braking & acceleration.

Since I only really care a bout the 200tw tires for the RTTC or Goodguys type events a Hoosier R compound may actually be what I really tune for.

I'd like to understand the logic behind a slick vs street tire tune better. I'm sure others won't mind reading that little diddy either.

Sure. Here goes ...

Assuming, we start with DOT tires of 200TW ... and dialed the suspension in thoroughly until we declared it was "optimum" & we could "find no more" ... then we put on Hoosier R6 racing slicks of similar height, width, sidewall size & wheel backspacing to maintain the same front & rear track widths ... here is what we would experience with no suspension changes:

1. On corner entry braking, the front suspension will compress quicker & farther & the rear suspension will rise quicker & farther. The car will experience more weight transfer from rear to front ... and may, or may not, lock up the rear tires easier, depending on several suspension factors. The car will have excessive pitch angle, excessive loading of front tires & excessive unloading of rear tires.

2. On corner entry "turn-in" ... while still braking ... the car will react/respond quicker, turning the front end of the car into the corner quicker. The car will experience more weight transfer from inside to the outside. Body/chassis roll will increase & be excessive. The biggest amount of weight transfer increase will be from the inside rear tire to the outside front tire. The tires on the inside of the corner will be underworked & the tires on the outside of the corner will be overworked ... the front more so than the rear. The car will lose traction on the inside rear tire & become loose ... unless the driver adjusts by braking softer & earlier during "1".

3a. If the driver does not adapt ... and the car gets loose on corner entry ... one of two things will happen (neither good). Either the driver "corrects" for the skid ... by turning the steering into it ... which adds cross weight & grip. At the point the car "catches" regaining grip ... the car angle & steering angle are F#%&*@ ... so after the car "catches" it will push like a dump truck through the middle of the corner ... and probably snap loose on exit. Or, if the driver doesn't correct the steering, the car will simply spin out.

3b. So ... assuming the Driver adjusts to brake softer & earlier keeping the handling neutral on corner entry ... when the steering is "set" & on its arc for the middle of the corner ... and the driver releases the brakes ... the car will experience slightly more roll angle, which was already excessive, due to the increased grip on the slicks . What happens next is dependent on the rebound valving of the front shocks . If there is not enough, the front will rise & the rear will settle too early*, causing the inside rear tire to reengage too early* & the inside front tire to become unloaded too early* ... leading to a mid-corner push condition.

Additional shock "low speed" rebound valving will help this situation by delaying the transfer*, as will the other tuning changes I'll outline. While on track, the driver could help this situation by lengthening their braking zone. Meaning get off the brakes later ... and use slightly less braking pressure, to arrive at the same corner speed. Do not confuse this with trail braking.

4. When it's time to pick up the throttle ... mid-corner, while the car is still turning ... the car will transition weight transfer to the rear ... and increase the car's roll angle, just until the driver starts unwinding the steering wheel. This may, or may, not lead to a push condition on cornering under throttle, depending on the timing* of weight transfer from the outside front tire to the outside rear tire. If the WT happens too spoon, it will push.

5. Soon after the driver starts to roll on the throttle, they start to unwind the steering wheel progressively. This will shift the transfer weight ... just as progressively from rearward & outward to simply rearward, by the time the car is accelerating straight. Again, this may, or may, not lead to a push condition on exit under throttle, but depending on the timing* of weight transfer from the outside front tire to the inside rear tire. If the WT happens too soon, it will push.

So ... what do we do? Drink beer.


Or, we could make these changes to optimize the set-up on the slicks:
A. Change to stiffer rate front & rear springs.

Note: If ... IF ... the front shock compression valving is adjustable enough ... we may be able to slow the rate of weight transfer from rear to front enough ... to restore the compression rate & distance to optimum ... and we may not. The "range" of the shock adjustment may simply not be enough. Frankly, going from 200TW to Hoosier R6's I doubt it. The only shock I know with that much range "might" be the JRI's.

B. Adjust your front & rear sway bars to stiffer settings ... or install bigger sway bars in the front & rear.

C. Fine tune the shock valving.
* Shock valving is the key tool for controlling the timing of events.

Fronts: Increase the rate of low speed rebound valving & fine tune the rate of compression valving to optimize the rate of front compression in dive with the new stiffer front springs.

Rears: Increase compression valving to slow the roll angle transition & help the car turn.

Note: If the car is still pushing on exit under throttle ... stiffen the high speed rebound valving on the front shocks and/or reduce the low speed rebound valving of the rear shocks a little.

D. Fine tune the car's front to rear grip balance by raising the rear roll center a little with your adjustable track bar or Watt's link.


How much change to achieve optimum? You won't know until you test. Just like you won't know what optimum is with the 200TW tires until you test also.

A experienced tuner like myself can get you in the ball park, but when you start pushing a car to its limits ... that when you truly find out what the car wants.

Important note: Lazy racers want to make one big change, and that is not optimum .. far from it. The only way to keep the car "happy" & truly optimized is making small to moderate changes in all these areas I've outlined.

Sometimes true optimum requires small amounts in other areas too, such as brake bias, track width (think thin wheel spacers) toe/ackerman, slight changes in ride height and/or rake, etc.

Make sense? Got questions ?



.

[FETorino]

Originally Posted by Ron Sutton

Hi Rob,


Make sense? Got questions ?

[/COLOR]

.

A wise man can learn more from a foolish question than a fool can learn from a wise answer.
Bruce Lee


I have plenty more foolish questions I'm just trying to make good use of the answers I already have to avoid being foolish. That might take some time.

If only I had a picture of a new part I could distract everyone with.

[Ron Sutton]

Originally Posted by FETorino

[I]
If only I had a picture of a new part I could distract everyone with.

When that happens to me, I just post photos of very attractive women.

You never did tell me if my front wheels were "Jiffypop" or not.

Look at the one on the left in between the rolling tool boxes. The 5-spoke style is "flat" ... but it's all the way out to the edge with no lip. Does it have to "crown out" to be "Jiffy Pop" ... or does just having no lip make it "Jiffy Pop?



.

[FETorino]

Originally Posted by Ron Sutton

When that happens to me, I just post photos of very attractive women.

You never did tell me if my front wheels were "Jiffypop" or not.

Look at the one on the left in between the rolling tool boxes. The 5-spoke style is "flat" ... but it's all the way out to the edge with no lip. Does it have to "crown out" to be "Jiffy Pop" ... or does just having no lip make it "Jiffy Pop?



.

I've looked at this picture several times and I still don't see any wheels.

Ron in So Cal is the wheel guy. Maybe he can see them.

[FETorino]

Originally Posted by Track Junky

Your killin' me dude

Dont mind me...Carry on......Please

Well Gae I told you this was coming back on post 120 something It's just taken me Flash time to get to it.

First I planned the build and got the chassis and drivetrain, wheels, tires and Brakes. Pretty much have that handled so....

Now it's time to plan the tune so I can buy the springs, shocks and bars. I still have a little bit of rework to do on some parts after my recent education into what I didn't know about chassis tuning.

I'll have some more big updates in a few weeks. For now I just want to focus on chassis tuning.

Ron was going to walk through roll center and it's use as a tuning tool. OBTW Ron I see you changed the picture but I still don't see the wheels.

That is something I didn't focus enough attention on initially. I guess it fell into the yada yada yada column and got overlooked. Not the end of the world but if you really want your car to be tunable it is somehting you should be educated on.

Originally Posted by FETorino

06-24-2012, 10:46 AM

My only theory is it will be an exciting car to drive and something a little different.

Well Todd you know as well as anyone once I get this thing to the track it will be a long road of tuning to get it "fast".

I've chosen some good parts and am working with good people for the base. I'll have plenty of power delivery and a chassis with good geometry to tune.

Spring rates, sway bar rates, shock valving, air pressure, yada yada yada..... There will be a lot of things to sort out. Step one I just need to keep focused on building a running car.

[Track Junky]

Couldn't agree more and I'm glad you've seen the light. My only gripe is having to ask questions about my car in your thread. Just dont feel it's appropriate.

My feeling is that all of the info that Ron has posted that is in general and not specific to your car should be placed in a "Suspension Technology" sticky for all to go to.
