  #11
Old 01-11-2016, 11:59 AM
IndyNova's Avatar
IndyNova IndyNova is offline
Senior Member

Join Date: Sep 2009
Location: Avon, In
Posts: 303
Thanks: 0
Thanked 0 Times in 0 Posts
Default

so you would essentially be bolting the subframe directly to the bottom of the car? what would the benefits be of doing this?
__________________
https://facebook.com/Protour69Nova
69 Nova-Ridetech, LS
Reply With Quote
  #12
Old 01-11-2016, 12:35 PM
jeds jeds is offline
Senior Member

Join Date: Jan 2014
Posts: 149
Thanks: 1
Thanked 0 Times in 0 Posts
Default

It's just to lower the car.

I can get the ride height I want without having to adjust the coil-overs too much which would impact the suspension geometry.

It also lets me lower the car without reducing ground clearance at the engine/trans.
Reply With Quote
  #13
Old 01-11-2016, 01:55 PM
IndyNova's Avatar
IndyNova IndyNova is offline
Senior Member

Join Date: Sep 2009
Location: Avon, In
Posts: 303
Thanks: 0
Thanked 0 Times in 0 Posts
Default

That's what I thought, I'd like to get mine lower too, I may have to check this out!
__________________
https://facebook.com/Protour69Nova
69 Nova-Ridetech, LS
Reply With Quote
  #14
Old 01-20-2016, 03:53 PM
frojoe's Avatar
frojoe frojoe is offline
Senior Member

Join Date: Aug 2007
Location: Vancouver, BC
Posts: 296
Thanks: 18
Thanked 1 Time in 1 Post
Default

I run no bushings (on rear of subrame, still need a ~1/2" spacer on the firewall mount due to difference in height) and a stock T56 and cut the whole tunnel out front firewall to rear firewall.. when you already modified your tunnel did you remove the under-floorpan stamped brace that's located between the seats? That was the first thing to hit my trans to my recollection. If you want to do it right you'll want to leave a ~1" gap around the trans for vibration/rotation and adjustment when fine tuning your driveshaft angles. My engine/trans angle is 0.5* down I believe, and I was able to trim the trans tunnel starting at about 3" back from the front firewall.. I was able to all the cutting and welding from inside the car.. I didn't need to cut all the way up to radially outwards on the firewall.
Attached Images

__________________
Joe
1972 Nova with twin 6466's and T56 Magnum in the works. Speedtech, Ridetech, Wilwoods etc. Swap thread --> http://ls1tech.com/forums/showthread.php?t=980909


Last edited by frojoe; 01-20-2016 at 03:55 PM.
